FOX devotes countless hours of research and development to design race-winning suspension that withstands incredible punishment and provides consistent performance you can rely on. Regardless of whether you are flying high over the desert or struggling to stick to a rock face on an off-camber climb, our shocks will give you the damping performance, suspension control and proper spring rate to get the job done.
Rebuildable and serviceable. Custom valving options available.
| Brand | FOX Offroad Shocks |
|---|---|
| Type | Smooth Body Shock |
| Weight | 10 - 18 lbs |
| Adjuster Type | DSC - Dual Speed Compression |
| Body Diameter (in) | 2, 2.5, 2.0, 3 |
| Body Finish | Clear Zinc Plated, FOX Grey Cerakote |
| Body Material | Steel, Aluminum |
| Bottom Mount | Eyelet |
| California Proposition 65 | ! WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Compressed Length (in) | 15.96, 16.18, 24.18, 21.18, 20.50, ... |
| Extended Length (in) | 25.40, 41.45, 24.45, 37.45, 28.45, ... |
| Eyelet Length (in) | 1.68, 1.95 |
| Fox Catalog | OFFROAD |
| Hose | -10 x 18.00, -8 x 14.00, -5 x 12.00, -10 x 24.00, -5 x 20.00, ... |
| Label Name | 3.0 FRS, SB, R/R, 10", Class 11, Rear (Side Mount), 2.0 FRS, SB, P/B, ECS2, DSC, 9.4", Right, 2.0 PES, SB (5/8"), R/R, 5", 2.0 PES, SB, R/R, 8", 2.5 FRS, SB, R/R, 14", ... |
| Mounting | 1/2 x 1-1/4, 1/2 x 1-1/2, .475 x 1.162 |
| Reservoir Dimensions | 2.17 x 11.00, 2.55 x 10.00, 2.17 x 8.00, 2.55 x 14.00, 2.550 x 8.00, ... |
| Reservoir Type | Remote, Rotating Piggyback, Rotating Remote |
| Seal Kit | 803-04-034 |
| Series | Factory Race, Performance Elite |
| Shaft Size (in) | 7/8, 5/8 |
| Top Mount | Eyelet, Welded Side Mount, Stem |
| Travel (in) | 9.44, 14.02, 6.59, 9.95, 10.02, ... |
| Travel (rounded) | 10, 12, 8, 14, 16, ... |
| Valving | 807-24-000, 807-24-301, 807-24-006, 807-24-058, 807-24-602, ... |
38 products in this series
